960W 6-Head Infinite Tornado LED Effect Light
This hybrid tornado effect light combines tornado rotation, sharp beam projection and wide wash lighting in a single fixture, solving three common lighting demands for entertainment venues without purchasing multiple separate moving lights. With upgraded total power of 960W, it delivers brighter beams and richer color saturation compared with lower-power versions.
What each effect solves for lighting design
- Tornado infinite rotation effect 6 heads rotate infinitely independently. The 12 light faces spin in variable speed and directions, creating a dynamic swirling tornado visual in hazy space. This effect replaces multiple small moving heads to build continuous flowing motion on stage, commonly used for club drops, DJ climax segments and grand opening moments. The higher 960W power brings stronger light output for larger banquet or nightclub spaces.
- Beam effect High-focus beam output cuts through haze to draw thin, defined light rays in the air. It is used for outlining stage space, highlighting performers and making dynamic aerial graphics. Compared with conventional single beam moving heads, 12 faces produce multiple beams at once for denser light array. The increased power makes the beam visible over longer distances.
- Wash + light guide bar effect The built-in light guide bar provides pixel-style auxiliary color wash. It delivers soft, full-area color coverage to tint backdrop, truss and venue walls. It works as ambient fill light and eliminates the need for extra wall wash bar lights in many medium and large venues.
Engineering & Installation Guide (Critical for buyers & lighting technicians)
- Application boundary & IP20 limitation: IP20 rating means the fixture is for indoor dry locations only. Not for outdoor, wet or high humidity environments. Dust protection only, cannot resist water splash.
- Suitable scenes: Nightclub / disco, banquet hall, wedding stage, livehouse, indoor concert, corporate event stage. The 960W higher power version fits medium-to-large venues with higher ceiling height.
- Mounting requirement: Designed for overhead truss hanging installation. Must use qualified safety cable as secondary protection. Static load calculation required for truss before rigging. Floor standing is optional but less common.
- Power & DMX signal daisy-chain: Support power in/out and DMX512 3-pin XLR input & output, allow signal and power daisy-chain connection of multiple fixtures. Important reminder: the 960W higher power draws more current; please calculate total load before chaining several units on one circuit.
- DMX channel mode selection guide
- Low channel modes (CH24, CH31): Quick programming, suitable for simple auto shows, small banquet / wedding events.
- Medium & high channel modes (CH44, CH59, CH79, CH149): Full pixel individual control for each light face, for professional lighting consoles, nightclubs and complex live performances.
Our factory supplies this tornado effect light with full testing before shipment. We also provide technical support for rigging, DMX programming and system integration for global stage contractors and rental companies. Contact our team to get the product datasheet, effect demo video and quotation.
